Introduce: Bridge Crane

According to different requirement of customer ( non-standard products), JLQ-2.0 series of products have realized combination of different parts. Within the shortest time, we are not only able to offer detailed technical specification and drawings to our customers, but also customize cranes conforming to the requirement of customers.

Description:

Product category: This crane includes box-type bridge, large cart traveling mechanism, small cart and electrical equipment.

This series of cranes adopt advanced electromotor, speed reduction gear and brake, which are produced by specialised manufacturers, as a result of which made standardization and generalization of all parts.

Usage: JLQ-10 Series Bridge Crane with Hook is widely used in factories, workshop and warehouse, etc, for the general loading, unloading, lifting and transportation indoor or outdoor fixed span.

To guarantee safety, lifting mechanism is equipped with weight limiter and height limiter. Traveling mechanism uses polyurethane buffer with long stroke and small buffer force. Driver's cab is comfortable with broad vision. which makes the operation of the crane easier.

The crane is equipped with maintenance suspending cage, convenient for the maintenance of large cart integrator.

Note: when outdoor using, rain proof equipment is necessary.

Bridge Crane Features:

Advanced manufacturing technology. According to different requirement of customer ( non-standard products), JLQ-2.0 series of products have realized combination of different parts. Within the shortest time, we are not only able to offer detailed technical specification and drawings to our customers, but also customize cranes conforming to the requirement of customers.

Bridge Crane Usage:

JLQ-1.0 Series Bridge Crane with Hook is widely used in factories, workshop and warehouse, etc, for the general loading, unloading, lifting and transportation indoor or outdoor fixed span. JLM-2.0 series 10-50/10t double beam Portal Crane with hook series is suitable for the loading and unloading of outdoor warehouse, stock ground, railway freight station, port cargo area, etc. It is also used for special operations by equipping with specialized lifting devices.

Bridge Crane

Bridge Crane Specifications

DOUBLE BEAM PORTAL CRANE WITH HOOK


Bridge Crane

Capt1020\532\550\10
Duty
A5
Span(m)S1822263035182226303518222630351822263035
Litting   HeightH11011101110121012
H2010.4511.4510.7312.7310.9212.92
H365216420
H40438664
SpeedHoistingMainm/min7.67.27.55.9
Aux012.39.57.8
Traverse43.844.642.444.6
Travelling4041404135354141
Main Dimensions (mm)H21000011000104501145010730127301092012920
H360005000200010006000400020000
H460005000400030006000600060004000
L16800880073009300780010500800011000
L26800880073009300780010500800011000
L3830010300880010800930012000950012500
S150007000500070005000750050008000
S250007000500070005000750050008000
S308709801195
B8000850085009000850080008500
B097501042010250109201174511570
dvivingwheels/drivedwheels2\22\24\44\4
Total   Motor Power(kw)39496979108150
Max   Wheel Loading (kn)200220240275300330350400450480240260275285300345360375400430
CaraneRail43kg/m or QU80
Power   Supply3-Phase A.C 50Hz 380V

Conducting device of small cart adopts deformed steel rail and   cable conductor device.    Standardization, serialization and universal design in components.   Crane power supply form includes cable mandrel type (left or right side) and   conductor type(left or right side).    Both are available. Driver's cab has good vision, equipped with   interactive console panel, flexible to operate, stable and comfortable.  It can be customized to add fan, air   heater, air cooler, air conditioner and interphone, etc.Please advise us the   working condition like highest temperature, lowest temperature and power   source type when you choose your own crane. We are also able to design   special size according to customers' requirement.


BRIDGE CRANE


Bridge Crane

This   series of cranes adopt advanced electromotor, speed reduction gear and brake,   which are produced by specialised manufacturers, as a result of which made   standardization and generalization of all parts.  To guarantee safety, lifting mechanism is   equipped with weight limiter and height limiter.  Traveling mechanism uses polyurethane   buffer with long stroke and small buffer force.  Driver's cab is comfortable with broad   vision, which makes the operation of the crane easier.  The crane is equipped with maintenance   suspending cage, convenient for the maintenance of large cart integrator.
1.   The wheel pressure data showed in the chart is for crane used indoor. When   using the crane outdoor, the wheel pressure shall increase 5%
2.   H0 is the increasing height of the buffer;
3.All   parts can be added adjustable-speed function according to customers'   requirement.
LADLE CRANE


Bridge Crane

Ladle   crane is a type of metallurgy bridge crane for steel factory. It is one of   the main equipment for lifting and transportation in the process of steel   making and continuous casting. It is mainly used for charging bay to add   molten iron to converter or electric furnace, in molten iron receiving bay to   lift the molten iron to turret of continuous casting machine or in refining   bay to lift the molten iron to finery, and there are minorty of ladle crane   used for casting steel ingot or parts.Ladle crane can be divided into 3   categories as follows according to entire structure:Four-beam four-rail   double cart ladle crane, four-beam six-rail double cart ladle crane, double   beam double rail single cart ladle crane.
1.Large   load for lifting to meet the capacity of converter.
2.Speed   of lifting has been improved so that it can suit to load and transport in hot   temperatureand in high efficiency.
3.Security   measures have been added to the ladle crane.
4.Main   and auxiliary lifting mechanism, main and auxiliary small cart and large cart   speed is adjusted by 10:1. The low speed is convenient for location.
5.The ladle crane is equipped with stroke   limit, load limit, measuring display instrument, more than 10 kinds of safety   devices to guarantee safety of operation and maintenance, to meet the   requirement of use entirely.



Export Cases

-Main markets: America, Canada, Mexico, the Middle East, Africa, Australia, Russia, Europe, Japan, Vietnam, India, etc
-Exhibitions: 2016.11 OSEA, 2018.5 OTC, 2018.11 OSEA, 2019.10 Kormarine, 2019.11 ADIPEC, 2020.11 Bauma China

FAQ

Q1:Are you factory or business company?

Juli Sling is an OEM&ODM manufacturer with nearly 38 years of history. Focusing on research and development and manufacturing of rigging.

Q2:What is your terms of delivery?

Accept EXW, FOB, CIF, etc. If you have any other choices or requirements, we could negotiate it together to help you find the most convenient and favorable one.

Q3:How does your factory do regarding quality control?

Quality is priority. We always attach great importance to quality controlling. Skillful workers care every details during the production; Strict quality testing in each process; Authoritative testing reports can be provided for customer.

Q4:What payment method is available?

By T/T, L/C, Other methods can be negotiated together.
